Working area (L*W): 3000×1500mm
X-axis running area: 1500mm
Y-axis running area: 3000mm
Z-axis running area: 200mm
Min. line width: 0.1-0.2mm
X/Y axis Position Precision: 0.05mm/m
X/Y axis Repeated Position Precision: ±0.02mm
Max. Running Speed: 120m/min
Max. accelerated speed: 1.2G
Machine weight: 7500 kg
Max. Load on working table: 1000kg
Phase: 3 phase
Voltage: 380V
Frequency: 50Hz / 60Hz
Power consumption: 15KW/H
Machine dimensions: 8500x2900x1900mm

Configuration:
Fiber Laser Source: nLight Manufactured in USA
Transmission System: YYC rack and pinion manufactured in Taiwan
Guide Rail: Hiwin Linear Guide manufactured in Taiwan
Speed Reducer: Manufactured by Motorreducer in France
Motor: Fuji Servo Motor manufactured in Japan
Laser Head: Swiss Raytools (Auto Focus)
System: Cypcut
Low Pressure Aviation Aluminium Gantry: Manufactured by Beyond Laser
